XPID200 PDA Handheld Badge Reader

Contact Us

Hardware

XPID200 PDA- Android 13 Handheld Badge Verifier

Introducing the XPID200, the NEW FCC and CE Certified Android 13 handheld badge reader, designed to read any RFID technology.

Benefits Include:

  • Handheld PDA integrated with Multi-Technology badge reader
  • Supports iClass, Prox, Indala, Mifare, PIV, Safetrust & many more!
  • Full RFID SDK available for card read/write requirements
  • IP65 rated device (Dust, Heavy Rain, Snow, 1.5m drop)
  • Cellular, WiFi, Bluetooth, 1D/2D Barcode, GPS, Camera Options

Performance Characteristics

Processor Cortex A73 2.0GHz octa-core
Operating System Android 13.0
Memory 3GB RAM/32GB ROM, MicroSD (max 256GB expansion)
Drop Spec 5ft./1.5 m drop to concrete across the operating temperature range
Barcode Engine 2D CMOS Imager Barcode Scanner | Honeywell N6703 2D Scan Engine
Camera (rear) 13.0 Megapixel Auto Focus w LED Flash (front) 5.0 Megapixel
Battery
Rechargeable Li-Ion Polymer, 3.8V, 5200mAh

Physical Characteristics

Handheld Dimensions (without Cradle) 170.8mm(H)x81mm(W)x28.6mm(D)±2 mm
Display 5.5 in Gorilla Glass 3 9H TFT-LCD(720×1440) backlight touch screen
Temperature Range Operating Temp: -20°C to 50°C
Storage Temp: -20°C to 70°C
Humidity 5%RH to 95%RH (non-condensing)
Expansion Slot 2 PSAM, 1 SIM, 1 TF
Dust & Water Proof IP65, IEC compliance

Network Characteristics

WLAN 2.4GHz / 5.0GHz Dual Frequency, IEEE 802.11 a/b/g/n/ac
Bluetooth Bluetooth Class v2.1+EDR, Bluetooth v3.0+HS, Bluetooth v4.2
Cellular (Nano-SIM) TDD-LTE Band 38, 39, 40, 4 | FDD-LTE Band 1, 2, 3, 4, 7, 17, 20
WCDMA(850/1900/2100MHz) | GSM/GPRS/Edge (850/900/1800/1900MHz)
GPS GPS (embedded A-GPS), accuracy of 5 m

RFID Module Support

Low Frequency (LF): HID / Indala / FarPointe / EM / CasiRusco / Pyramid / Securakey
High Frequency (HF): iClass / SEOS / Mifare / DESFire (EV1, EV2, EV3) / PIV / CAC / TWIC / Felicia / Legic / Allegion / Stid / ISO14443 / ISO15693 / ISO14443 A/B / Gallagher / Paxton
Ultra-High Frequency (UHF): EPC GEN2 / ISO 18000-6C
Mobile Credentials: HID Mobile Access / Safetrust / BLE / NFC
Barcodes: 1D / 2D Barcode / PDF417 / QR-Code

Cradle

Standard Interface USB / Power Jack / Extra Battery Charger
Ethernet Interface RJ-45 Ethernet Interface (optional cable)



XPID200 Handheld Badge & Biometric Reader
XPID200 in Cradle with Extra Battery Charger
